5000Turns Winding Nanocrystalline Core Coils for Hall Effect Sensor

HeHere the short introduction of our gapped nancorytalline core coils for hall sensor application:

A) A). High Precision & high Permeability Nanocrystalline Core

The core made of nanocrystalline magnetic material. The nanocrystalline cores with high magnetic permeability, significantly improving the sensitivity of Hall sensors.

B) .3mm Air Gap Cutting by Advanced Line Cutting Skills

We use advanced wire cutting technology to cut the core into a 3mm air gap. The thin air gap can not only improve the stability of Hall sensors and reduce the adverse effects of external factors such as temperature and vibration, but also effectively buffer the changed magnetic energy. When the load is reduced, the magnetic core air gap will release the stored magnetic energy, reduce waste, improve efficiency, reduce losses, and extend equipment life.

C) .Extra large storage loop, supporting 5000 turns of machine winding

We use advanced winding machines, and we have the large wire storage loops. which guarantee our automated production line can accurately wind 5000 turns of 0.7mm copper wire, ensuring high quality and consistency of each magnetic core coils.

Customized design based on below product  details:

• Current Input (AC, DC):
• Current Output / Voltage Output:
• Turns Ratio:
• Accuracy:
• Size request:
• Inner Hole Diameter:
• Is it Split core type or Ring type:

Main Application:

Our hall effect sensor can be mounted to existing panels, such as control centers or load centers, to measure or monitor wattage. Which is widely used for:

Electrical fire monitoring system, power supply monitoring system for fire fighting equipment, smart power system, smart grid, station area transformation, environmental protection extra testing, small current grounding system, relay protection, motor protection system.

As an leading manufacturer of amorphous and nanocrystalline core products, Coilcore provides quality services to customers with high-performance products and one-stop solutions. By leaving a message below to get more details about  Hall Sensor quickly!
